E6013 Grade1 is a mild steel welding rod with rutile type coating with top quality.

E-mail: max@tensileweld.com

Phone / WhatsApp / WeChat: +8615066821752


Product Description

E6013 Grade1 is a mild steel welding rod with rutile type coating with top quality.

AWS A5.1 E6013

BS EN IS0 2560-B-E4313A

CSA W48-06 E4313

JIS Z3211 D4313

GB/T 5117 E4313

Type of Covering: High Cellulose, Potassium

Welding Position: F,H,HF,OH,V

Type of Current: AC, DCEP or DCEN

Features & Applications

E6013 is a mild steel welding rod with rutile type coating. It welds on AC & DC and widely used in ordinary tensile strength mild steel structures. Especially suitable for intermittent welding to sheet steel and small work pieces as well as cosmetic welding with smooth and shiny appearance.

Rutile type E6013 – Grade 1

Coating contains 55% natural rutile(95% TiO2)

Low spatter and smoke, no smell

Chemical Composition of Deposited Metal(%)

C Mn Si S P Ni Cr Mo V
Standard ≤0.20 ≤1.20 ≤1.00 ≤0.035 ≤0.040 ≤0.30 ≤0.20 ≤0.30 ≤0.08
Typical 0.070 0.41 0.26 0.021 0.023 0.018 0.027 0.002 0.001

Mechanical Properties of Deposited Metal(AW)

Yield Point
Reh (Mpa)
Tensile Strength
Rm(Mpa)
Elongation
A4(%)
Impact Value(J)
20°C 0°C
Standard ≥306 400-560 ≥22 — ≥47
Typical 395 480 29 110 80

The standard of mechanical properties conforms to shipping institutions and the certificate of inspection would follow it unless the purchaser has special requirement.

X-ray radiographic inspection: Grade II



Size,Piece & Recommended Current(AC or DC⁺)

Size(mm) 2.5×300 2.5×350 3.2×350 4.0×400 4.0×450 5.0×400 5.0×450
Piece(5kg) ≈303 ≈258 ≈157 ≈90 ≈80 ≈59 ≈52
Current(A) F,H 60-90 60-90 80-130 150-190 150-190 180-250 180-250
V,OH 50-80 50-80 80-110 130-170 130-170 — —

Notice: Normally the rod do not need to re-dry in case it is affected with damp seriously it should be re-baked at 150°C for 30-60 minutes before use.

All Position Welding
